Ory Hydra Hello world

bash
git clone
https://github.com/ory/hydra

Run ORY HYDRA service

bash
docker-compose -f quickstart.yml \
  -f quickstart-postgres.yml \
  up --build

We will get Thank you in terminal:

text
Thank you for using Ory Hydra v2.0.3!

Give authentication to the customer or third party

The OAuth 2.0 client uses port 4444 and 4445. The former is Ory Hydra's public endpoint, the latter its administrative endpoint. For more information head over to Exposing Administrative and Public API Endpoints.

Exposing administrative and public API endpoints

Ory Hydra serves APIs via two ports:

  • Public port (default 4444)
  • Administrative port (default 4445)

The public port can and should be exposed to public internet traffic. That port handles requests to:

text
/.well-known/jwks.json
/.well-known/openid-configuration
/oauth2/auth
/oauth2/token
/oauth2/revoke
/oauth2/fallbacks/consent
/oauth2/fallbacks/error
/oauth2/sessions/logout
/userinfo

The administrative port shouldn’t be exposed to public internet traffic. If you want to expose certain endpoints, such as the /clients endpoint for OpenID Connect Dynamic Client Registry, you can do so but you need to properly secure these endpoints with an API Gateway or Authorization Proxy. Administrative endpoints include:

text
All /clients endpoints.All /keys endpoints.All /health, /metrics, /version endpoints.All
/oauth2/auth/requests endpoints.Endpoint /oauth2/introspect.Endpoint /oauth2/flush.

Let’s create the OAuth 2.0 Client: (administrative)

bash
docker-compose -f quickstart.yml exec hydra \
  hydra create client \
  --endpoint http://127.0.0.1:4445/ \
  --format json \
  --grant-type client_credentials

response (administrative)

json
{
  "client_id": "f95a8d96-9d15-471a-8f7b-b37fbab3c1f1",
  "client_name": "",
  "client_secret": "B~~zBRuoBpdAByNhq8fMkq_d2C",
  "client_secret_expires_at": 0,
  "client_uri": "",
  "created_at": "2023-01-30T07:50:43Z",
  "grant_types": [
    "client_credentials"
  ],
  "jwks": {},
  "logo_uri": "",
  "metadata": {},
  "owner": "",
  "policy_uri": "",
  "registration_access_token": "ory_at_3BY4izdL2AuYCXyT-g_B5nPUZp2RiGTzY-itCztfViI.TFOwoqKQlnSlzpw1PZ9blQuCSFVw50DLxQA1zY3RueI",
  "registration_client_uri": "http://127.0.0.1:4444/oauth2/register/f95a8d96-9d15-471a-8f7b-b37fbab3c1f0",
  "request_object_signing_alg": "RS256",
  "response_types": [
    "code"
  ],
  "scope": "offline_access offline openid",
  "subject_type": "public",
  "token_endpoint_auth_method": "client_secret_basic",
  "tos_uri": "",
  "updated_at": "2023-01-30T07:50:43.099053Z",
  "userinfo_signed_response_alg": "none"
}

Let’s perform the client credentials grant: (public)

bash
docker-compose -f quickstart.yml exec hydra \
  hydra perform client-credentials \
  --endpoint http://127.0.0.1:4444/ \
  --client-id $client_id \
  --client-secret $client_secret
bash
docker-compose -f quickstart.yml exec hydrahydra perform client-credentials--endpoint
http://127.0.0.1:4444/--client-id f95a8d96-9d15-471a-8f7b-b37fbab3c1f0   --client-secret
Y~~zBRuoBpdAByNhq8fMkq_d2CACCESS TOKEN
ory_at_HjvbarTv4ZngKuhF0JhM4AhdnReXJfT0Fb__8MFc5uA.qftzDg6vfqoT46fQqJPGmSSWSH8YG6ZxHLsrTIZznH4
REFRESH TOKEN <empty>            ID TOKEN <empty>            EXPIRY  2023-01-30 08:58:16 +0000 UTC

Let’s perform token introspection on that token. Make sure to copy the token you just got and not the dummy value. ( administrative )

bash
docker-compose -f quickstart.yml exec hydra \
  hydra introspect token \
  --format json-pretty \
  --endpoint http://127.0.0.1:4445/ \
  ory_at_HjvbarTv4ZngKuhF5JhM4AhdnReXJfT0Fb__8MFc5uA.qftzDg6vfqoT46fQqJPGmSSWSH8YG8ZxHLsrTIZznH4{
  "active": true,  "client_id": "f95a8d96-9d15-471a-8f7b-b37fbab3c1f0",  "exp": 1675069097,  "iat":
  1675065497,  "iss": "http://127.0.0.1:4444",  "nbf": 1675065497,  "sub":
  "f95a8d96-9d15-471a-8f7b-b37fbab3c1f0",  "token_type": "Bearer",  "token_use": "access_token"}

install jq on ubuntu

bash
sudo
apt install -y jq

[ client of administrative ]

Next, we will perform the OAuth 2.0 Authorization Code Grant. For that, we must first create a client that’s capable of performing that grant: (administrative)

bash
code_client=$(
docker-compose -f quickstart.yml exec hydra \    hydra create client \    --endpoint
http://127.0.0.1:4445 \    --grant-type authorization_code,refresh_token \    --response-type
code,id_token \    --format json \    --scope openid --scope offline \    --redirect-uri
http://127.0.0.1:5555/callback)code_client_id=$(echo $code_client | jq -r
'.client_id')code_client_secret=$(echo $code_client | jq -r '.client_secret')
bash
docker-compose -f quickstart.yml exec hydra \
  hydra create client \
  --endpoint http://127.0.0.1:4445 \
  --grant-type authorization_code,refresh_token \
  --response-type code,id_token \
  --format json \
  --scope openid --scope offline \
  --redirect-uri http://127.0.0.1:5555/callback
json
{
  "client_id": "9184ee7f-ffb1-4f0b-af5a-99ce52d8f324",
  "client_name": "",
  "client_secret": "rt1tpaWDiZwCetWDROH-LFpN.t",
  "client_secret_expires_at": 0,
  "client_uri": "",
  "created_at": "2023-01-30T08:31:38Z",
  "grant_types": [
    "authorization_code",
    "refresh_token"
  ],
  "jwks": {},
  "logo_uri": "",
  "metadata": {},
  "owner": "",
  "policy_uri": "",
  "redirect_uris": [
    "http://127.0.0.1:5555/callback"
  ],
  "registration_access_token": "ory_at_qM2EmFkLsHUI_YjTe0uuJhkr2LiB8_VK04ilYIxXLe8.gLywrTZ4YGA8w8ziSV_ttm_9VP5mDoBME-Iki3kdo18",
  "registration_client_uri": "http://127.0.0.1:4444/oauth2/register/9184ee7f-ffb1-4f0b-af5a-99ce52d8f324",
  "request_object_signing_alg": "RS256",
  "response_types": [
    "code",
    "id_token"
  ],
  "scope": "openid offline",
  "subject_type": "public",
  "token_endpoint_auth_method": "client_secret_basic",
  "tos_uri": "",
  "updated_at": "2023-01-30T08:31:37.725833Z",
  "userinfo_signed_response_alg": "none"
}
